Part Number Max input voltage Bucks LDOs Charger(max) Support battery voltage(V) Gauge Package/pin/size(mm2)
AXP152 6.3V 4 7 NO NO NO QFN/40/5*5
AXP155 6.3V 5 10 NO NO NO QFN/40/7*7
AXP173 6.3V 2 4 linear 1.4A 4.2,4.35 YES QFN/32/5*5
AXP176 6.3V 1 3 linear 1.4A 4.2,4.35 YES WLCSP/23
AXP192 6.3V 3 4 linear 1.4A 4.2,4.35 YES QFN/48/6*6
AXP202 6.3V 2 5 PWM 1.8A 4.2,4.35 YES QFN/48/6*6
AXP216 6.3V 5 6 PWM 2.2A 4.2,4.35 YES QFN/48/6*6
AXP228 6.3V 5 14 PWM 2.2A 4.2, YES QFN/48/8*8
AXP229 6.3V 5 12 PWM 2.2A 4.2,4.35 YES QFN/48/8*8
AXP288 6.3V 6 14 PWM 2.8A 4.2,4.35 YES QFN/48/9*9

Click here to know more

AC100 Integrates with three I2S/PCM interface, 2 channel DACs and 2 channel ADCs ,one RTC module and a Capless stereo headphone driver with 18mW@1.8V
AC101 Integrates with one I2S/PCM interface, 2 channel DACs and 2 channel ADCs,and a Capless stereo headphone driver with 18mW@1.8V
AC108 Integrates with quad-channel audio ADCs with 108 dB dynamic range (A-weighted) @ 0 dB boost gain and one I2S/PCM interface with 2 data out line
AC200 Integrates with one I2S/PCM interface, 2 channel DACs and 2 channel ADCs,10M/100Mbps Ethernet-PHY,and a CVBS video module
